Long-Term Performance of CP Systems on Bridge Structures
CATHODIC PROTECTION · BRIDGES · REINFORCED CONCRETE · LONG-TERM PERFORMANCE
Installing cathodic protection is only the beginning. Long-term performance depends on whether the system continues to deliver adequate current, whether its components remain functional, and whether monitoring still provides enough information to evaluate protection.
A Federal Highway Administration study launched in 1994 examined the long-term performance of corrosion-protection systems installed on reinforced-concrete bridge decks, substructure elements, and a tunnel roadway slab. The work continued research begun through the Strategic Highway Research Program and included cathodic protection, corrosion inhibitors, and electrochemical chloride extraction.
THE QUESTION BEHIND THE STUDY
Install a Corrosion-Control System
↓
Operate It for Years
↓
Test Current Delivery & Polarization
↓
Determine Whether Protection Is Still Effective
How the Long-Term Bridge Study Began
In 1988, the Strategic Highway Research Program (SHRP), mandated by the U.S. Congress, launched several research programs focused on deterioration of reinforced-concrete highway structures.
Three SHRP efforts—identified in the original source as C-102-D, C-102F, and C-102G—established field sites to study methods for mitigating corrosion of reinforcing steel. The technologies included cathodic protection (CP), electrochemical chloride extraction (ECE), and corrosion inhibitors (CI).
After those programs concluded in 1993, the Federal Highway Administration initiated a five-year follow-up study in July 1994 to gather longer-term performance data from the field installations and associated laboratory specimens.
THE VALUE OF FOLLOW-UP STUDIES
Short-term commissioning can show whether a system initially operates. Long-term evaluation reveals whether anodes, overlays, wiring, instrumentation, rectifiers, and monitoring methods remain effective after years of actual service.
What the Researchers Evaluated
The broader program evaluated corrosion-control treatments at 31 bridge structures and one tunnel. Ten cathodic-protection systems became the focus of the case study summarized here.
Before evaluating system performance, investigators reviewed available information about the original concrete condition, CP installation, structure drawings, operating history, and prior monitoring.
EVALUATION METHODS REPORTED IN THE STUDY
- Electrical continuity testing
- Polarization and depolarization testing
- Embedded instrumentation evaluation
- Anode-to-reinforcing-steel AC resistance testing
- Review of operating history and system condition
Five Cathodic Protection System Types Were Evaluated
The systems represented several approaches to impressed-current cathodic protection for reinforced concrete. The original study included the following system types:
CONDUCTIVE COKE BREEZE
Conductive coke breeze anode systems used to distribute protective current.
CONDUCTIVE POLYMER
Mounted conductive polymer anode systems attached to the concrete structure.
TITANIUM MESH + OVERLAY
Titanium mesh anodes incorporated beneath a concrete or cementitious overlay on bridge decks.
TITANIUM MESH + SHOTCRETE
A titanium mesh anode encapsulated in a shotcrete overlay within the tunnel application.
CONDUCTIVE COATING
Conductive coating systems applied to concrete surfaces to function as part of the anode system.
Long-Term Results Varied Significantly by System
The study did not find one universal outcome. Some systems continued to perform satisfactorily after many years, while others showed declining performance or were considered ineffective.
01 · CONDUCTIVE COKE BREEZE SYSTEMS
Still providing required protective current
Three conductive coke breeze anode systems were reported as satisfactorily supplying the required current after approximately five, eight, and nine years of service, with no reported indication of anode degradation.
02 · MOUNTED CONDUCTIVE POLYMER SYSTEM
Components functioning, but protection was below expectations
The system components were reported to be operating, but the level of polarization suggested that corrosion mitigation was less effective than desired. The investigators noted that current-output adjustments might improve performance.
03 · TITANIUM MESH BRIDGE-DECK SYSTEMS
Satisfactory after extended service
Titanium mesh anode systems installed on three bridge decks were reported as performing satisfactorily after approximately six, seven, and twelve years of operation.
04 · TITANIUM MESH IN THE TUNNEL
The tunnel installation was considered ineffective
The titanium mesh anode system encapsulated in a shotcrete overlay within the Brooklyn Battery Tunnel was reported as not providing adequate protection and was considered ineffective by the investigators.
05 · CONDUCTIVE COATING SYSTEMS
Service life and deterioration became concerns
One conductive coating system reached the end of its reported service life in less than eight years. A second system continued to provide protection over much of the structure but was showing progressive deterioration.
LONG-TERM PERFORMANCE IS SYSTEM-SPECIFIC
A cathodic protection technology cannot be judged by its generic name alone.
Performance depends on system design, installation quality, concrete condition, anode configuration, current distribution, environmental exposure, operation, maintenance, and the ability to monitor the system over time.
The Monitoring System Became a Reliability Issue of Its Own
One of the most important findings had less to do with the anodes themselves and more to do with the instrumentation used to evaluate them.
The researchers found some degree of malfunction among embedded monitoring instruments at most of the sites. Voltage probes and molybdenum/molybdenum-oxide reference cells were identified as particularly prone to failure.
As embedded devices failed over time, fewer installations retained enough operational instrumentation to support straightforward performance evaluation.
YOU HAVE TO MAINTAIN THE MONITORING SYSTEM, TOO
A corrosion-control system may continue operating even after some embedded sensors fail—but confidence in the assessment can decline if the instruments needed to measure polarization, potentials, or other performance indicators are no longer reliable.
What Happens When Embedded Reference Cells Fail?
At locations where embedded reference cells were no longer available, the study reports that investigators used potential wells and external reference electrodes to obtain measurements.
The original study questioned the reliability of that substitute approach under the conditions being evaluated. It also concluded that the AC resistance test and associated criterion being used to assess embedded reference-electrode functionality deserved reevaluation.
That finding is a reminder that monitoring criteria themselves should be validated rather than assumed to remain appropriate indefinitely.
What Long-Term Cathodic Protection Management Requires
The study reinforces that cathodic protection should be managed as an operating system over the life of the structure—not treated as a one-time construction activity.
- Confirm electrical continuity and system integrity.
- Verify that protective current is reaching the intended reinforcing steel.
- Evaluate polarization or other applicable performance criteria.
- Inspect anodes, overlays, coatings, wiring, rectifiers, and connections.
- Maintain reference electrodes and other monitoring instrumentation.
- Track changes in output and performance over time.
- Investigate unexpected measurements rather than assuming sensor or system failure.
- Adjust system operation where appropriate and supported by the design.
- Plan for replacement or rehabilitation of components with finite service lives.
MANAGE CP AS A LIFECYCLE SYSTEM
Design & Install
↓
Commission & Establish Baseline
↓
Monitor Performance
↓
Maintain Components & Instrumentation
↓
Reassess & Adjust Over Time
The Bigger Lesson for Bridge Asset Management
Cathodic protection can be a valuable tool for mitigating corrosion of reinforcing steel in chloride-contaminated concrete, but long-term success depends on far more than the initial installation.
Some systems in this study continued performing satisfactorily after more than a decade. Others deteriorated sooner, and one tunnel installation was considered ineffective. At the same time, failure of embedded reference devices made continued performance evaluation increasingly difficult at several sites.
For infrastructure owners, the lesson is not that one historic CP system type is universally superior. It is that design, installation, monitoring, maintenance, and long-term operability must all be considered when evaluating lifecycle performance.
BOTTOM LINE
A cathodic protection system is only as useful as its ability to continue protecting the steel—and as the owner’s ability to verify that protection years after installation.
HISTORICAL STUDY NOTE
This case study summarizes research initiated in the 1990s and systems that had accumulated approximately 5 to 15 years of service at the time of evaluation. System technologies, monitoring criteria, standards, test methods, and current practice may have evolved. Present-day design and assessment should follow current project requirements, applicable standards, and qualified corrosion-engineering guidance.
SOURCE
This article by Jean Broge was originally published by Infrastructure Insights Magazine. Republished with permission.
The underlying study was presented at CORROSION99 and later included in AMPP/NACE bridge-related technical literature documenting historical cathodic-protection case studies.
